| Total Power Output |
2200W |
| Type |
|
| Type of Power Supply |
Power Supply |
| Form Factor |
|
| Dimension (W x H x L) |
76 x 336 x 40 mm |
| +5V |
- |
| +12V |
100A / 1200W 150A / 1800W 165A / 1920W 174.17A / 2090W 183.3A / 2200W (for UL/cUL only) |
| +3.3V |
- |
| 5V Standby |
1A |
| Input Voltage Range |
100-127Vac / 1200W 200-220Vac / 1800W 220-230Vac / 1980W 230-240Vac / 2090W 220-240Vac /
2200W (for UL/cUL only) 200-220Vac / 2090W (for UL/cUL only) 230-240Vdc / 2090W (for CQC only) |
| Input Frequency Range |
50-60Hz |
| Input Current Range |
1200W: 14 -11A 1800W: 10 – 9.5A 1980W: 10 – 9.8A 2090W: 10 – 9.8A
2200W: 12 -11A (for UL/cUL only) 2090W: 14 -11A (for UL/cUL only)
2090W: 10 – 9.8A (for CQC only) |
| Output Type |
Gold Finger (27 Pair Connector) |
| 8Pin / 4Pin (12V) Connector |
- |
| PFC |
|
| Voltage / Current |
PMBus 1.2 Support |
| Energy Efficiency |
96%+ Efficiency |
| 80 Plus Certification |
80 Plus Titanium
|
| Validated Systems |
SYS-2029TP-HC0R, SYS-2029TP-HC1R, SYS-2029TP-HTR, SYS-5039MP-H8TNR, SYS-5049A-TR,
SYS-6029TP-HC0R, SYS-6029TP-HC1R, SYS-6029TP-HTR, SYS-7049GP-TRT, SYS-F619H6-FT,
SYS-F619P2-FT, SYS-F619P2-FT+, SYS-F619P2-RC0, SYS-F619P2-RC1, SYS-F619P2-RT,
SYS-F619P2-RTN, SYS-F619P3-FT |
| Validated Chassis |
CSE-217HQ+-R2K20BP2, CSE-747BTS-R2K20BP, CSE-827HQ+-R2K20BP2 |
Product Environmental
Compliance |
RoHS and REACH compliant, details available upon request |
