| Dimensions (WxHxD, mm) |
Pedestal
218 x 455 x 726.3 |
| Motherboard |
MH53-G40 |
| CPU |
- AMD Ryzen Threadripper PRO 7000 WX-Series Processors
Up to 96 cores, 192 threads
Single processor, TDP up to 350W
|
| Socket |
1 x sTR5 |
| Chipset |
AMD WRX90 |
| Memory |
- 8 x DIMM slots
DDR5 memory supported only
8-channel memory architecture
RDIMM/3DS RDIMM supported
Memory speed: Up to 5200 MT/s
|
| LAN |
2 x 10Gb/s LAN ports (1 x Broadcom BCM57416)
Support NCSI function
1 x 10/100/1000 Mbps Management LAN |
| Video |
Integrated in ASPEED AST2600
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp |
| Audio |
Realtek ALC897 HD Audio Codec
Supports 2/4/5.1/7.1 channel configurations
Rear 3 x Audio jacks (Audio in/Audio out/Mic)
Front 2 x Audio jacks (Audio out/Mic) |
| Storage |
4 x 3.5"/2.5" SATA hot-swappable bays
Additional 4 x 3.5"/2.5" SATA hot-swappable bays (optional)
Note: Storage card is required to support NVMe and SAS drives.
RAID
RAID 0/1/10/5 |
| Peripheral Drives |
5.25" space reserved for ODD device |
| Expansion Slots |
Slot_7: PCIe x16 (Gen5 x16) slot
Slot_6: PCIe x16 (Gen5 x16) slot
Slot_5: PCIe x16 (Gen5 x16) slot
Slot_3: PCIe x16 (Gen5 x16) slot
Slot_2: PCIe x16 (Gen5 x16) slot
Slot_1: PCIe x16 (Gen5 x16) slot
4 x M.2 slots for storage:
- M-key
- PCIe Gen5 x4, from CPU
- Support 2280/22110 cards
1 x M.2 slot for Wi-Fi:
- E-key
- PCIe Gen3 x1, from FCH
- Supports 2230 cards |
| Internal I/O |
1 x TPM header |
| Front I/O |
1 x USB 3.2 Gen1 (Type-C)
2 x USB 3.2 Gen1 (Type-A)
2 x Audio jacks (Audio out/Mic)
1 x Power button with LED
1 x Reset button
1 x Power LED
1 x Storage activity LED
1 x System status LED |
| Rear I/O |
1 x USB 3.2 Gen2x2 (Type-C) (from FCH)
3 x USB 3.2 Gen2 (Type-A) (from CPU)
1 x VGA
1 x COM
2 x RJ45
1 x MLAN
3 x Audio jacks (Audio in/Audio out/Mic)
1 x ID button with LED |
| TPM |
- 1 x TPM header with SPI interface
- Optional TPM2.0 kit: CTM010
|
| Power Supply |
Single 2000W ATX 80 PLUS Gold power supply
AC Input:
- 100-115V/ 13A, 50-60Hz, 1200W
- 115-200V/ 15A, 50-60Hz, 1500W
- 200-240V/ 12A, 50-60Hz, 2000W
DC Output:
- Max 1200W/ 100-115V~
+12V/ 100A
+5Vsb/ 4A
- Max 1500W/ 115-200V~
+12V/ 125A
+5Vsb/ 4A
- Max 2000W/ 200-240V~
+12V/ 166.7A
+5Vsb/ 4A |
| System Management |
ASPEED AST2600 Management Controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
Dashboard
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status …etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
Advanced power capping
LDAP / AD / RADIUS Support
Backup & Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings |
| OS Compatibility |
Red Hat Enterprise Linux (x86_64)
Ubuntu (x86_64)
Windows 11 (x64) |
| System Fans |
Middle fan: 3 x 120x120x38mm (6,400rpm)
Rear fan: 1 x 120x120x25mm (2,800rpm)
|
| Operating Properties |
Operating temperature: 10°C to 30°C
Operating humidity: 8%-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing) |
| Packaging Content |
1 x W773-H5D-AA01
1 x CPU fansink |
