サイズ(W×D) |
10.4" x 10.5" |
CPU |
Supports AMD EPYC 9004 (with AMD 3D V-Cache Technology) and 97x4 series processors |
ソケット |
Single Socket SP5 (LGA 6096) |
チップセット |
System on Chip |
システム メモリ |
8 DIMM slots (1DPC)
Supports DDR5 288-pin RDIMM, RDIMM-3DS |
DIMM Sizes |
RDIMM: 96GB (2R)
RDIMM-3DS: 512GB (2S8Rx4) |
Max DIMM Frequency |
4800 MHz |
PCIe x 16 |
SLOT6: PCIe5.0 / CXL1.1 x16
SLOT5: PCIe5.0 / CXL1.1 x16
SLOT4: PCIe5.0 / CXL1.1 x16
SLOT3: PCIe5.0 / CXL1.1 x16 |
SATA コントローラ |
AMD EPYC 9004 (16 SATA 6Gb/s):
2 MCIO |
Others |
2 MCIO (PCIe5.0 x8)
2 MCIO (PCIe5.0 x8 or 8 SATA 6Gb/s)
1 MCIO (PCIe5.0 x4) |
M.2 slot |
2 M-key (PCIe5.0 x4); support 2280/2260/2242/2230 form factor |
BMC コントローラ |
ASPEED AST2600 |
IPMI Dedicated GLAN |
1 Realtek RTL8211F for dedicated management GLAN |
グラフィックス |
ASPEED AST2600 |
VGA ポート |
1 DB15 (VGA) |
USB 3.0 ポート |
2 Type-A (USB3.2 Gen1) |
Lan ポート |
2 RJ45 (10GbE)
1 dedicated IPMI |
オペレーティング•システム |
Microsoft Windows:
- Server 2019 (64bit)
- Server 2022 (64 bit)
Linux:
- RedHat Enterprise Linux Server 8.6 (64bit) / Server 8.7 (64bit) / Server 9.0 (64bit) / Server 9.1 (64bit)
- SUSE SLES 15.4(64 bit)
- UBuntu 20.04.5 (64 bit) / 22.04 (64 bit) / 22.10 (64 bit)
Hypervisor:
- VMWare ESXi/ 7.0 U3i / 8.0
- CITRIX Hypervisor 8.2.1 |
